Multimodal classroom segment classification — full-dataset report

1. Three prediction tasks

Each annotated segment carries three independent labels. We trained separate classifiers for Function (instructional activity), Organization (whole class / groups / individual), and Engagement (how many students appear engaged). The same video-grouped splits and segment clips were reused; only the target column changed.

2. Data and inputs

• 764 segments from 73 videos under edu_all/ (vs prior local subset: 290 / 29).
• Per segment: 8 RGB frames (224×224, ImageNet normalization) + mono WAV at 16 kHz.
• Split by video: train 541 / validation 88 / test 135 (no segment leakage). One segment lacks frames.
• Written comments are excluded from all reported models (not available at deployment).
• Label drops (runtime filter; files kept on disk): Function drops Discussion (n=7, 0 in val); Engagement drops Half and Some (0 in val). Organization keeps all 3 classes. These labels had no (or effectively no) validation examples, so keeping them would let train-only classes inflate or distort macro-F1 without a fair held-out check — a form of evaluation leakage. We drop them at train/eval time instead.

Label counts (full manifest, n=764)

Prior subset was the same spreadsheet restricted to 29 on-disk videos (Discussion entirely missing). Macro-F1 there was noisier (val 59 / test 41).

3. Evaluation metric

Models are scored with macro-averaged F1 (macro-F1): for each class we compute precision and recall, take their harmonic mean (F1), then average across classes with equal weight. Unlike accuracy, macro-F1 does not let the model look good by always predicting the majority class.

We select checkpoints by validation macro-F1 (88 segments after drops). Test (128–135 segments) is reported but not used for selection.

Training loss: class-weighted cross-entropy (weight ∝ 1 / train frequency). That encourages rare-label learning during optimization; macro-F1 measures held-out balance afterward.

4. Modeling approaches (full-data sequence)

Unlike the subset report’s A–D grid (including warped mel128 and focal fine-tune “v2”), the full-data plan starts from a frozen ResNet baseline and adds temporal pooling and audio only where they help.

5. Audio encoding

5.1 From WAV to log-mel

1. Load segment WAV; resample to 16 kHz mono if needed.
2. Mel spectrogram: 64 mel bins, FFT 400, hop 160 (~10 ms per frame).
3. Log compression: log(mel + 1e-9). Networks always see log-mel.

5.2 Native timing (mel_time)

Keep one time column per hop (~100 frames/s). Clips shorter than ~5.1 s are zero-padded to 512 frames with a mask; longer clips are truncated to the first 512 frames (~5 s of audio content). A 1D conv + masked mean pool yields a 128-D vector.

5.3 ASR uncertainty (not transcripts)

On the subset, Whisper → MiniLM transcript embeddings were unstable: ASR often emits fluent text on noisy classroom audio. Here we keep only confidence / uncertainty statistics from whisper-tiny and concatenate them with mel (and video). The transcript string is never fed to the classifier.

6. Results (macro-F1)

Validation = model selection; test = held-out videos. Bold / green rows are the current best model per target.

Function (5-class; Discussion dropped)

Organization (3-class)

Engagement (3-class; Half/Some dropped)

7. Function examples (best val model: mel + ASR)

Validation clips from the best Function model (mm_mel_time_asr, n=88 after dropping Discussion). Thumbnail is the first of eight sampled frames (click to enlarge). Each row includes a playable WAV of the segment. Comments are annotations only, not model inputs.

Correctly classified (5)

Frame	Segment + audio	Comment	True	Predicted
	1910 · 0:14:00–0:16:29	Teacher telling students what they needed to to	Direction	Direction
	1908 · 0:00:00–0:09:22	Teacher talking about the lesson - Teacher projecting his laptop on the screen -	Lecture	Lecture
	1909 · 0:03:31–0:04:32	Students going to grab iPads	Transition	Transition
	1909 · 0:08:24–0:32:00	Students working on their tasks - Teacher moving around and helping students	Working	Working
	1908 · 0:18:49–0:19:44	Teacher telling students to use the Wash brush to erase the shape they created - Teacher showing a new shape on the s...	Direction	Direction

Misclassified (5)

Frame	Segment + audio	Comment	True	Predicted
	1909 · 0:04:32–0:08:24	Teacher giving directions to students	Direction	Lecture
	1924 · 0:04:26–0:11:44	teacher asking questions	IRE/MS	Lecture
	1921 · 0:10:00–0:26:34	teacher explaining the lesson	Lecture	Working
	1909 · 0:32:00–0:36:43	Students leaving the class after finishing the tasks	Transition	Working
	1908 · 0:16:34–0:18:49	Students working on their laptops - teacher moving around and talking to students	Working	Lecture

×

8. Findings

• Expanding from 290→764 segments makes metrics more stable; label drops remove zero-val rares from the primary score.
• A temporal head over frame embeddings helps Organization and Engagement; Function prefers plain mean-pool + audio.
• Native-timing log-mel helps Function; alone it does not clearly help Org and hurts Engagement.
• ASR uncertainty (not transcript text) is a useful additive signal for Function and especially Organization.
• Engagement remains primarily a visual / attention problem on this data — stacking classroom audio degraded val macro-F1.

9. Future directions (estimated usefulness)

1. Diarization summary features — cached speaker-count / overlap / speech-fraction stats. Org and Function already benefit from audio clarity cues; “who talks how much” is a natural next side-channel for grouping.
2. V3: 16 frames + temporal head — denser frame sampling on the video-led task. Engagement rejected audio; more visual temporal detail is the cleanest next upgrade there.
3. Stronger video model (VideoMAE / TimeSformer) — pretrained clip transformer instead of bag-of-ResNet frames. Largest architectural jump if denser frames plateau, especially for Engagement and Function transitions.
4. Light backbone fine-tune (layer4) on current Function/Org winners. A little adaptation of ImageNet filters may help with ~500 train clips without full 3D cost.
5. Balanced mini-batch sampling (vs weighted CE only). Minorities (Transition, Small Group, Most) still drag macro-F1; this is the deferred imbalance A/B.
6. 3D CNN (R3D / R(2+1)D) — true spatiotemporal convolutions on the frame stack. More video-like than pooling embeddings, but heavy on CPU and easy to overfit.
7. Larger ASR for uncertainty only (e.g. Whisper-small). Same confidence idea with better estimates if tiny-Whisper signal is real but noisy.
8. Larger audio encoders (PANNs / BEATs) fused with mel — rich pretrained audio beside log-mel. Mixed on the subset; lower priority now that mel+ASR already works for Fun/Org.
9. Stratified video re-split / GroupKFold — better coverage of rares and uncertainty on metrics. Cannot invent Discussion/Half examples; mainly reporting hygiene.
